Click Open.Ĩ: In the Spreadsheet to PLC I/O Utility dialog box, leave the Settings box blank. Click Open.ĥ: From the Projects list, click the expansion node next to PLC_Modules_NFPA to expand the drawing list.Ħ: On the Import/Export Data tab, Import panel, click PLC I/O Utility.ħ: In the Select PLC I/O Spreadsheet Output File dialog box, in the User directory, which opens by default, select demoplc.xls. ■ Skip to step 6.ģ: In the Project Manager, click Open Project.Ĥ: Browse to where you installed the exercise files. If it is open but not active, in the Project Manager, do the following: ■ Right-click PLC_Modules_NFPA. Process: Create PLC Drawings from a Spreadsheetġ: If the Project Manager is not displayed, on the Project tab, Project Tools panel, click Manager.Ģ: If PLC_Modules_NFPA is the active project, skip to step 6. Objective: In this project you use the default demoplc.xls spreadsheet and hard-coded default settings to generate three PLC drawings. Completion of the Using the Spreadsheet to PLC I/O Utility Lesson
